工业级柜式DLP,3D智能打印设备

智能化打印控制与优化

高速度与高精度的结合

全方位的人性化设计

长时间批量化稳定生产

广泛的打印材料选择

Industrial-grade DLP 3D intelligent printing equipment

Intelligent control & optimization of printing

Combination of high speed and high precision

All around user-friendly design

Long-term stable mass production

Wider selection of printing materials

滑到下一屏
UV LED光源 UV LED light source

使用顶级的美国TI DLP技术,加上UV LED光源,Ultracraft快速成型技术在保证高精度打印的同时,有着高速且低耗的特点。

With top-notch TI DLP technology from the US and UV LED light source, HeyGears Ultracraft's rapid prototyping technology guarantees high-precision printing with high speed and low consumption.

数据表 144*81*300 mm ±37.5 μm 25-100 μm 1920* 1080P UV LED 385 nm 20-50 mm/hour

UV投影,逐层固化液态光敏材料
累积2D平面达到3D的效果

SOLIDIFY LIQUID PHOTOSENSITIVE MATERIALS
LAYER BY LAYER BY USING UV PROJECTION
AND ACHIEVE 3D EFFECT BY ACCUMULATING 2D PLANE

固化步骤1

使用软件将3D文件
切成无数个2D平面图像

Cut 3D files into countless
2D flat images by using software

固化步骤2

再使用UV投影
逐层固化液态光敏材料

Then solidify liquid photosensitive
materials layer by layer by using UV projection

固化步骤3

通过累积2D平面
达到3D的效果

Achieve 3D effect
by accumulating 2D plane

菱形

菱形

SP技术 (Side Peel™)

SP技术采用侧面剥离方式,减小剥离过程的拉力,提高打印成品率。

Side Peel™

Side Peel™ adopts a side peeling method to reduce the pulling force of the peeling process and improve the printing yield.

菱形

SS技术 (Smart Separation™)

Ultracraft A2采用专利授权的SS技术,让打印机能实时调整每一层的剥离力度,极大加快打印速度、增强打印稳定性。

Smart Separation™

HeyGears Ultracraft A2 features patented Smart Separation™ that allows the printer to adjust the peeling strength of each layer in a real time, greatly speeding up printing and enhancing printing stability.

菱形

菱形

打印机
菱形

高级图像算法

高级图像算法通过对3D文件的精细处理,使成品表面细腻光滑,满足用户对平滑质感的需求。

Advanced image algorithm

Advanced image algorithm makes the surface of the finished product fine and smooth through the fine processing of 3D files, satisfying the user's demand for smooth texture.

菱形

传感器收集数据100%保存,让特定时间打印机所处的各项状态都可追溯。
Data collected by a sensor is 100% saved, allowing the status of the printer traceable at a specific time.
智能传感器改变机械化单一动作,让A2能思考,主动进行打印过程的控制。
Smart sensor changes the mechanized single action, allowing A2 to think and actively control the printing process.
线条 线条

搭载系列智能传感器

EQUIPPED WITH SMART SENSORS

线条

力学 力学传感器 Mechanical sensor

温度 温度传感器 Temperature sensor

液位 液位传感器 Liquid level sensor

湿度 湿度传感器 Humidity sensor

防夹手 防夹手传感器 Anti-pinch sensor

打印机
线 圆 材料循环系统 Material circulation system
线 圆 主动排风系统 Active exhaust system
线 圆 可调节触摸屏 Adjustable 10.2 inch touch screen
线 圆 RGB状态指示灯 RGB status indication light
线 圆 脚触开关 Foot-sensing switch

人性化设计

让打印高效到底

Ultracraft A2的设计理念从使用者角度出发,尽一切可能为使用者提供最大的便利。

节省人力,提高效率。

USER-FRIENDLY DESIGN

MAKE PRINTING EFFICIENT

HeyGears Ultracraft A2 is designed from the perspective of users to provide the maximum convenience to users.

Save manpower and increase efficiency.

touch

智能软件 操作快捷,使用舒心

INTELLIGENT SOFTWARE IS QUICK TO OPERATE AND EASY TO USE

Ultracraft A2搭载卓越高效的智能软件。PC端使用的UP任务管理系统支持打印文件的系统管理,协助用户提前做好生产排期。机器本身搭载的UEC控制软件对打印机进行本地调试,在打印过程中实时显示打印运行的各项指标参数,实现打印过程可视化,方便用户操作。

HeyGears Ultracraft A2 is equipped with superior and efficient intelligence software. The UP task management system used by the PC supports system management of printing files to assist users in scheduling production in advance. The UEC control software provided by the machine itself performs local debugging of the printer, and displays various indicator parameters of the printing operation in a real time during the printing process to realize the visualization of the printing process and facilitate the operation of the user.

pad

线条 UEC (Ultracraft Embedded Control)控制软件 HUEC (HeyGears Ultracraft Embedded Control)
control software

线条 UP (Ultracraft Planner)任务管理系统 HUP (HeyGears Ultracraft Planner)
task management system

打印机
稳定程度坐标 稳定程度坐标
线条
打印机 printers 传统打印机弊端
稳定程度坐标 稳定程度坐标
线条
产量是传统FDM打印机的10倍 With an output 10 times of traditional FDM printers
